R700
PREMIUM LARGE FLOOR-STANDING TOWER SPEAKER
The R700 offers uncompromising sonic performance. This full throttle loudspeaker adds two 8” woofers to deliver massive impact with striking audio clarity and detail. Perfect for use as a reference stereo pair or as the cornerstone of the ultimate home cinema.
FORM AND FUNCTION
Exceptional Cabinetry
Reserve’s sleek cabinetry hides a world of audio innovation. Cabinets are carefully cross-braced to best eliminate unwanted interior resonances. Rounded exterior corners help disperse sound broadly around the room with minimal diffraction, creating an open sound stage.
Optional Height Module
MULTIDIMENSIONAL SOUND
For immersive vertical sound, add compatible Reserve R900 height modules (sold separately). These optional height modules perform beautifully with the latest home theater technologies, including: Dolby Atmos, DTS, DTS:X, DTS:X Virtual, IMAX Enhanced, and Auro-3D.
RESERVE R700
Every detail
Delivers clear and detailed high-end response up to 40Khz for improved high frequency signals for today’s high-quality audio.
Listening to Atmos and DTS:X-enabled content on Reserve Series speakers brings you deeper into the story or music every time.
IMAX Enhanced certification guarantees an unforgettably huge and dynamic home theater experience when enjoying IMAX Enhanced movies, television shows and music.
Reserve R700
Details & Specifications
- Speaker Type - Floorstanding Loudspeaker
- UOM (Sold As) - Each
- Tweeter - 1" Pinnacle Ring Radiator
- Mid-range/Mid-bass - 6 ½” Turbine Cone
- Woofers - Two 8" Polypropylene
- Overall Frequency Response - 30Hz - 50kHz
- Frequency Response (-3dB limits) - 38Hz - 38kHz
- Recommended Amplifier Power - 50 - 300W
- Amplifier Output Compatibility - 8Ω / 6Ω / 4Ω
- Minimum Impedance (ohms) - 3.6Ω
- Sensitivity (2.83V/1m) - 88dB
- Tweeter/Mid-range Crossover Frequency - 2700Hz
- Mid-range/Mid-bass Crossover Frequency - 350Hz
- Product Dims W x H x D (Includes width of feet) - 320.7 x 1143.8 x 428.3mm 12.6 x 45 x 16.9 in
- Product Weight (each) - 79.1 lbs/35.9 kg
- Shipping Weight - 94.4 lbs/42.8 kg
- New CRC (Mid-Range Enclosure Type) - Sealed with CRC
- Mid-Bass / Woofer Enclosure Type - Floor Firing Power Port with X-Port
- Available Finishes - Black/Walnut
- Feet - Spike and Pad
- Wall-Mountable (keyhole slots) - No
- Binding Posts: Nickel-plated 5-Way - Dual
- Hi-Res Certified - Yes
- IMAX Certified - Yes
- Shipping Dims (WxHxD) - 550 x 423 x 1250mm (21.6 x 16.7 x 49.2) in
