ATRIUM SUB100
OUTDOOR 200W SUBWOOFER
Can be planted in your landscaping, hung from your ceiling or the eaves, or installed anywhere you want to mix great sound with the great outdoors
Designed to Blend In
Safety and Security
Flexibility
Weatherproof
Housed in a moulded and sealed acoustically ideal resin enclosure and marine-certified with IPX66 rating, our guarantee of years of weather-proof outdoor performance.
Dynamic Balance®
Massive 10-inch long-throw Dynamic Balance® driver technology eliminates driver distortion for deeper, cleaner bass even at higher volumes.
Capacitive Coupling Technology
Dual 2-inch voice coil design reproduces bass from both stereo channels, producing more power in the lower frequencies with the help of Capacitive Coupling Technology. You get big outdoor bass for big outdoor impact.
The included grille protects the woofer and will hold up in the outdoor environment.
The included waterproof IP68 rated junction box easily connects other outdoor speakers and is approved for in-ground use.
200 Watt downward-firing subwoofer delivers earth-shaking bass.
Atrium Sub100
Details & Specifications
- Total Pieces - 1
- Included Accessories - • (1) Weatherproof Aluminum Grille • (1) Waterproof IP68 Rated Junction box • (4) Wire Nuts • (1) Owner’s Manual
- Cabinet Warranty - 3 years
- Drivers Warranty - 3 years
- Original Purchaser Only - Yes
-
Carton 1 - 14.75" (37.47 cm) h x 20.75" (52.71 cm) w x
20.25" (51.44 cm) d - 20.25 lbs (9.19 kg)
- Total Pieces - 1
- Subwoofer Array Driver Enclosure Type - Acoustic Suspension with Color-Impregnated Resin Shell
- Subwoofer Array Driver Complement - • (1) 10" (25.4 cm) d (Round) Long-throw Dynamic Balance composite cone driver with dual voice coils and butyl rubber surround - Subwoofer - Voice Coil 2" (5.08 cm) d
- Height - 11" (27.94 cm)
- Width - 16.9" (42.93 cm)
- Depth - 16.9" (42.93 cm)
- Weight - 16.75 lbs (7.6 kg)
- Nominal Impedance - 8 ohms
- Sensitivity (1 watt @ 1 meter) - 88 dB
- Lower and Upper -3dB Limits - 50 Hz → 110 Hz
- Recommended Amplifier Power Per Channel - 10 watts → 200 watts
- Peak Power Handling - 200 watts
- Midrange/Woofer Crossover Frequency - 150 Hz
- Power Handling (per channel) - 10 watts → 200 watts
- Mounting Type - Security eyebolt
- Available Orientations - Horizontal
- Mounting Type - Keyhole Slots
- Available Orientations - Horizontal
